System of Venturi Tubes

Venturi tubes have used in particular applications for particularly dirty fluids or at the special high temperature for intermittent use for where is not recommended for normal fans

They are specifically designed for each application on the customer's request.

Tell us your needs, We will offer you the best solution designed specifically for you!

We also produce orders for single pieces and prototypes!

For more information, please contact our technical department

sistema venturi aspirazione
VENTILATORE VENTURI 1 (2)
IMGP0976 (3)
IMGP0714
IMGP1031
p 026
IMGP0974 (3)

Technical characteristics



  • Build-in right or left installation motor,(on request it can be isolated from the treated fluid), in single-phase and three-phase versions, both with optional adjustable speed. Available in versions with Voltage and Hz for international use

  • Discharge port orientable as desired

  • Standard fan fixing systems, flanged, to be welded or customizable according to your needs

  • The fan can be installed in a remote position

  • The whole system is made up of a Venturi tube, piping, case, impeller, vanes and a motor protection grid in STAINLESS STEEL, a material with great resistance to corrosion and atmospheric agents, a guarantee of durability in excellent aesthetic-functional conditions in many years.

  • Various process connections available: weld-in, flanged, folder-flanged, clamp, plug-in and other types on request.
